2.5 ton EP forklift electric EFL252 4050mm mast height for logistics.

2.5 ton EP forklift electric EFL252 4050mm mast height for logistics use lithium-ion technology which supports opportunity charging so it can be charged at preferable time during the day without disrupting working schedules.

EFL252 features its high strength mast and tapered roller steering axle for better stability and endurance.The truck is able to be operated outdoors, even on uneven road.

2.5 ton EP forklift electric EFL252 4050mm mast height for logistics is suitable for narrow aisle usage and multiple working conditions, the upgraded steering axle and mast extend its durability, making it a real workhorse to realize heavy duty applications.

Distinguishing mark		Unit	Value
Manufacturer			EP
Model designation			EFL252
rated capacity	Q	kg	2500
Load center distance	c	mm	500
Wheelbase	y	mm	1595
Self weight (include battery)		kg	3830
Dimensions
Height, mast lowered	h1	mm	2060
Free lift (load backrest)	h2	mm	140
Lift height	h3	mm	3000
Height, mast extended	h4	mm	4050
Height of overhead guard (cabin)	h6	mm	2160
Fork dimensions		mm	40X122X1070
Overall length	l1	mm	3573
Overall width	b1/ b2	mm	1154
Turning radius	Wa	mm	2290
performance data
Travel speed, laden/ unladen		km/h	44512
Lifting speed		m/s	0.28/ 0.37
Lowering speed		m/s	0.45/ 0.5
Electric-engine
Drive motor rating S2 60 min		kw	10
Lift motor rating at S3 15%		kw	12
Battery voltage/nominal capacity K5		V/Ah	80V/205AH
The maximum allowed size battery			731X 608X 326mm
