Model |
Desc |
Qty |
EXW (RMB) |
|
|
HY350 mobile self loading concrete mixer with 270°rotation function |
Yuchai 85KW engine Concrete output productivity 3.5 cbm With 270°rotation function double reverse camera . Automatic weighting system with printer 4 batches per hour. Hydraulic Torque Converter Transmission, 4 wheel drive ,articulated style. 16/70-20 tyres . Turbo-Wom rotation . automatic upper water system ,with pump and pipes. warning light, back sound, radio, fan, hand brake, extinguisher, window hammer, Easy damaged spare parts ,tool box. |
1 |
|
|
|
Total |
|
|
|
|
|
Name |
Item |
Spec |
||
|
Overall machine |
Net weight |
8100kg |
||
|
Overall size |
7600*2360*4380mm |
|||
|
Transmission |
Full Hydraulic |
|||
|
4WD |
||||
|
Brake |
Air brake |
|||
|
Chassis |
Off-road |
|||
|
Wheelbase |
2850mm |
|||
|
Loader bucket |
Capacity |
0.5cbm |
||
|
Control |
Hydraulic |
|||
|
Tilt Angle |
30% |
|
||
|
Speed |
High speed |
0-25KM/H(40KM/H) |
||
|
|
|
Low speed |
0-9KM/H |
|
|
Min turning radius |
6.5m/r |
|||
|
Tyre Model |
16/70-20 |
|||
|
Engine |
Type |
Yuchai |
|
|
|
Rated Power/RPM |
85KW/2600RPM |
|||
|
Max Torque/RPM |
460N.W/1400RPM |
|||
|
Cylinder |
4 |
|||
|
Starter |
Electric |
|||
|
Cooling type |
Water Cooling |
|||
|
Maxing Drum
|
Drum full capacity |
5.8cbm |
||
|
Drum work capacity |
3.5cbm |
|||
|
Bank angle |
16° |
|||
|
Self rotation angle |
270° |
|||
|
Rotation speed |
21R/min |
|||
|
Chute |
Swing Angle |
≥60° |
||
|
Angle control |
Hydraulic |
|||
|
Size |
138CM |
|||
|
Loader |
Weight model |
Computer control |
||
|
Concrete standard |
C15.C20.C25.C30 |
|||
|
Accuracy |
Cement |
≤±2%/time |
||
|
Relative error |
≤±3%/time |
|||
|
Water |
≤±1%/time |
|||
|
Additive |
≤±1%/time |
|||
|
Admixture |
≤±2%/time |
|||
|
Loader control |
Hydraulic control 4 way stick |
|||
