origin

ZHEJIANG HuaHe forklift company

Model

HH25Z

Power type

Gasoline/LPG

Rated capacity

kg

2500

Load center

mm

500

Dimension

Lift height

mm

3000

Free lift height

mm

130

Fork size

N*U*L

mm

1070*122*40

Mast inclination

Front/Back

deg

6/12

Front o-verhang

mm

482

Overall dimensions

Length to face of fork

mm

2630

Overall width

mm

1150

Mast lowered height

mm

2095

Overhead guard height

mm

2120

Turning radius

mm

2380

Min. right angle aisle width

mm

2000

Performance

Travel speed

No load

km/h

9/20

Full load

mm/s

8.8/18.5

Lift speed

mm/s

480

Max. gradeability

%

20

Max. drawbar pull

Kn

14

self weight

kg

4020

Wheel&Tires

Tires

Front

7.00-12-12PR

Rear

6.00-9-10PR

Tread

Front

mm

970

Rear

mm

970

Wheelbase

mm

1650

Min. ground (no ldad/full load)

Mast

mm

152/132

Frame

mm

158/138

Drive units

Battery

Voltage

V/Ah

12/90

Engine

Model

K21

origin

Japan

Rated output/r.p.m

kw/r.p.m

33/2300

Rated torque

N.m/r.p.m

142/1600

No.Cylinder

1982

Displacement

cc

4

Type

Hydraulic

Shift

(Fwd/Rwd)

1/1

Operating pressure

Mpa

17.5
