XCMG official 4*4 diesel forklift 2.5 ton 3 ton 3.5 ton with forklift part.

XCMG Diesel Forklift provide you with multiple choice as per your real need,we have different reliable engines for choice.

XCMG Diesel Forklift engines are specifically designed for the forklift use,with low fuel consumption,less noise and vibration,all these features improve the whole performance of the forklift.

High efficiency is also delivered through the performance of the axles,the excellent brake system make sure the forklift operate with safety,the steering axle provide prompt and precise feedback to the driver when steering.

Advantages and Highlights:

• Robust and Reliable Diesel Engine

• Ergonomically design

• Wide-view Mast and Container Mast for Choice

• Fully Integrated Frame and Suspension Chassis

• Excellent Cooling System and Heat Releasing System

• Easy to maintain and repair

• Lower Gravity

• Emergency Stop Switch

• Multiple Option Available for Choice

Model		FD25T	FD30T	FD35T
Power Type		Diesel	Diesel	Diesel
Rated Load Capacity	Q(kg)	2500	3000	3500
Load Centre	C(mm)	500	500	500
Rated Lift Height	H3(mm)	3000	3000	3000
Free Lift Height	H2(mm)	100	100	100
Fork Size (L×W×T)	mm	1070×120 ×40	1070×125 ×45	1070×125 ×50
Mast Tilt Angle (F/R, α°/β°)	deg	6°/12°	6°/12°	6°/12°
Fork Overhang (Wheel Center to Fork Face)	X1(mm)	479	484	484
Rear Overhang	X2(mm)	520	595	635
Ground Clearance (Bottom of Mast)	H7(mm)	130	145	145
Length to Face of Fork (Without Fork)	L1(mm)	2643	2773	2813
Overall Width	B1(mm)	1150	1225	1225
Overhead Guard Height	H5(mm)	2215	2235	2235
Tyre (Front x 2)	mm	7.00-12-12PR	28×9-15-12PR	28×9-15-12PR
Tyre (Rear x 2)	mm	6.00-9-10PR	6.50-10-10PR	6.50-10-10PR
Total Weight	kg	3950	4340	4840
Battery	V/Ah	12/90	12/90	12/90
