Product Details

CBM15FB Forklifts

1、Ac drive,stronger power.
2、Lifting double protection,more safe.
3、Shelving design,better protection of goods during transportation.
4、Five fulcrum design,automatic adjustment of auxiliary wheel.
5、Touch-free walk proximity switch for durability.
6、Adopt the import controller,more stable and reliable.



Description
Unit
Parameter value
Model
CBM15FB
Configuration No.
56/68
Rated capacity
kg
1500
Load center distance
mm
600
Wheel base
mm
1370
Driving mode
Walking
Tyre type(front/rear)
PU
Driving wheel/Bearing wheel number
1/4
Driving wheel size
mm
φ210*70
Bearing wheel size
mm
φ80*70（Double wheels)
Min.fork lowered height
mm
80
Max.fork lifting height
mm
195
Max.lifting height
mm
115
Overall fork width
mm
560/680
Inside width between forks
mm
240/360
Fork length
mm
1150/1220
Fork width
mm
160
Fork thickness
mm
50
Truck body length
mm
1845/1730
Truck body width
mm
680
Truck body length（With handle)
mm
1188
Truck body length(Without handle)
mm
940
Min.Turning radius
mm
1350
Min.right angle stacking aisle width for pallets 800×1200
mm
2150
 Min.right angle stacking aisle width for   pallets 1000×1200
mm
2230
Travelling speed,loaded/unloaded
km/h
4/4.5
Lifting speed,loaded/unloaded
mm/s
28/38
Lowering speed,loaded/unloaded
mm/s
38/33
Gradeability,loaded/unloaded
%
6/15
Drive motor
KW
0.75
Lifting motor
KW
0.84
Battery voltage / capacity
V/Ah
24V/60Ah
Brake
Electromagnetic/Regenerative
Controller
Curtis
Battery weight
kg
26.5
Total weight(with battery)
kg
220
