XCMG Offical 4x2 tractor truck head NXG4180D3WA.
Advanced power
It is equipped with weichai WP10/WP12/WP13 four-valve low-speed
High-torque gas engine new generation of German BOSCH (doctor) gas EC union
Woodward OH6.0 new generation of electric control system, lower gas consumption.
Match Fastre 12jsd160/180/200t aluminum casing gearbox
Vehicle-energy-saving technology, power developed 20%, gas consumption reduced by 10%, save 50,000 yuan per year.
Advanced value
Lower vehicle deadweight -- 1000L lightweight cylinder application, chassis suspension system, drive axle, rim through lightweight design and a variety of new material applications.
Engine auxiliary braking - reduce frequent driving braking, the vehicle is lighter, more safe driving.
Optional with hydraulic retarder - to ensure the safety of mountain driving, can bid farewell to the water tank.
500,000km maintenance-free rear axle + 5.5t maintenance-free front axle + increase variable section brake pad.
industry super width 840mm sleeper.
matching horizontal shock absorber - full filter turbulence, ride comfort.
vehicle noise control -- fully optimized through NVH design, door double seal structure +7-layer 30mm engine insulation process, noise reduction.
Main parament | Drive type | 4×2 | |
Gross vehicle weight(kg) | 42000 | ||
Wheelbase(mm) | 3600 | ||
Engine | Type | WP10.375 | |
Rated output (kw/rpm) | 276/2200 | ||
Max torque(Nm/rpm) | 1460/1200-1600 | ||
Emission standard | EURO Ⅲ | ||
Fuel tank(L) | 400 | ||
Transmission | Standard | Type | 12JSD160T |
Ratio | 15.53-1.00 | ||
Axle system | Front axle | 7.5t | |
Middle axle | / | ||
Rear axle | 13t MAN TEC | ||
Suspension | Leaf spring | 3/4+3 | |
Balanced suspension | / | ||
Frame | Longitudinal beam(height×width×thickness)/mm | 300×80×(8+8) | |
Tire | Type | 12.00R20 | |
Brake system | Brake | Drum | |
ABS | equipped | ||
Body | Type | 50# | |
Lifting | / | ||
Electrical system | Sound box | Equipped | |
Cab | Series | HANVAN G7 | |
Type | High cab | ||
Left/Right driving | LHD | ||
Front suspension | Air bag | ||
Rear suspension | Air bag | ||
Seats | Ordinary seats | ||
Bunk | Equipped | ||
Window regulator | Electric | ||
Rear window | Equipped | ||
Air conditioning | Equipped |
