XCMG Official 3 Ton Small Wheel Loader LW300FV Chinese Mini Front Wheel Loaders.



XCMG LW300FV wheel loader is a self-propelled earthmoving machine which is hinged in front of the chassis and consists of a moving arm, a connecting rod mechanism and a loading bucket. It can be used for shoveling, transporting, unloading and leveling. If the corresponding working device is replaced, it can also be used for bulldozing, lifting, loading and unloading wood and steel pipes.



Performance Characteristics:

1. High energy-conservation, efficiency, reliability, and comfort.
2. All load-carrying portions of the drive axle are solid and firm enough to ensure excellent overload resistance and meet the needs of diversified high strength and high load operations.
3.The full-view cab sufficiently takes in consideration the human-machine functions to realize high operation safety and comfort.


Optional parts:
A/C/ 1.8m3 Blade bucket/ 2.1m3 Lignt material Blade bucket/ 2.5m3 Lignt material Blade bucket / 1.8m3 Reinforced bucket

Description

Specification

Unit

Rated operating load

3000

kg

Bucket capacity

1.8

Machine weight

10600±200

kg

Dump clearance at maximum lift

2930

mm

Reach at maximum lift

1010

mm

Wheel base

2600

mm

Tread

1850

mm

Max. breakout force

130±5

Kn

Max. horse power

95±5

Kn

Total hydraulic cycle time

8.8

s

Min. turning radius over tyres

5165±50

mm

Articulation angle

35

°

Overall machine dimension LxWxH

7245x2482x3050-3210

mm

Engine Model

WP6G125E333

Rated power/Speed

92/2000

Kw/rpm
