XCMG official Small Concrete Slip Form Paver Xgnc600 price
Payment
Shipping
Support Sea freight · Land freight · Air freight
Recommendation
Specs & Compare
Weight: 3200Kg
Dimension(L*W*H): 4200×2500×2100mm
Model Number: Xgnc600
Brand Name: XCMG
Paving Width: 600mm
Power(W): 36.8kW
Production Capacity: 10000 Units/Year
Certification: ISO9001: 2000, CE
Add models to compare
Description



XCMG official Small Concrete Slip Form Paver Xgnc600 price



XGNC600 multifunctional slipform paver is a multi-purpose cement concrete construction equipment independently developed by our company. It can be used for multiple purposes, and can realize multiple mold configurations. It is widely used in the field of cement concrete structures such as small road drains, gutters, kerbs, shoulder stones, etc., replacing the traditional technology and significantly improving the construction quality and speed of cement concrete structures.

Front crawler walking, hydraulic drive, proportional control two-speed motor and large speed ratio planetary gear reducer ensure paving stability and improve slipform paving quality; The steering ratio of the front track is controlled, and the steering is accurate.

The engine power is strong; The hydraulic system adopts load-sensitive variable control, and supplies oil according to the actual load size and speed, with low oil consumption, energy saving and environmental protection.

The humanized design of the operation console, the man-machine interactive control screen and the clear graphical identification symbols make the paver easy to operate.

ItemXGNC600
Maximum side paving height600mm
Maximum paving width600mm
Paving speed0~15m/min
Travel speed0~20m/min
Engine modelYCF3050-T302 (Yuchai)
Rated power/speed36.8kW/2400r/min
Diesel tank capacity100L
Track width300mm
Track length1340mm
Climbing capacity≥ 15%
Minimum turning radius3500mm
Outrigger hydraulic lifting stroke430mm
Twister speed0~65r/min
Size of auger feeding device1600mm long, 300mm diameter
Hydraulic vibrator interface2
Vibrating rod frequency0~200Hz
 water tank capacity158L
Transport dimension (long × wide × High)4200×2500×2100mm
Operating Weight3200Kg
