Item

Unit

XLZ2103S

Operating parameters

Milling width

mm

2100

Maximum milling depth

mm

400

Milling rotor

Cutter spacing

mm

18

Number of cutters

144

Diameter of milling wheel(with cutter)

mm

1380

Diesel engine

Manufacturer

Weichai Power Co., Ltd.

Cooling type

Water-cooling + air inter-cooled

Model

WP13G530E310

The quantity of cylinder stator

6

Related power

kW

353

Engine speed

rpm

2100

Oil consumption: Full load

kg/h

69.86

Speed/gradeability

Working speed

km/h

0-3.2

Traveling speed

km/h

0-23

Theoretical gradeability(working gear)

%

20

Ground clearance

mm

350

Weight/load

Front axle load

kg

16000

Rear axle load

kg

5500

Shipping weight

kg

21000

Working weight

kg

21000

Tank volume

Fuel tank

L

650

Hydraulic oil tank

L

380

Water tank

L

1000

Voltage of electric system

v

24

Overall dimension of shipping

Machinery(length*width*height)

mm

9232 x 3162 x 3450
