XCMG 9m 30 ton Reach Stacker for Logs and Steel Pipe.

XCMG Reach Stackers:

XCMG reach stackers include K series (diesel engine) and E series (pure electric) reach stackers

XCMG K Series Reach Stackers:

XCMG's K series reach stacker features good safety, high degree of intelligence, comfortable operation, energy saving and environmental protection, and it meets the requirements of the high-end market.

Applicable Working Conditions of XCMG K Series Reach Stacker XCS31W:

Construction of tower tube and pipeline

Highlights of XCMG XCS31W Reach Stacker:

1. Strong powered by Volvo engine and Dana gearbox

2. Parker hydraulic system, IFM controller hydraulic and electric control scheme to ensure quick operation

XCMG XCS31W Reach Stacker Optional Configurations:

smart brakes, precise weighing, panoramic images, etc.

Applicable working scope	Construction of tower, pipeline；Logs, steel pipe
Basic configuration	Engine：Volvo TAD1151VE
	Gearbox model:DANA 15.7TE30510
	Drive axle model：Kessler D102PL341
	Tyre model：18.00-25
	Rated power/speed：265kw/2100rpm
	Maximum static load：150t
Spreader	Model：XDJ310W
	Rotation angle：+30°/-30°
	Side shift distance：±400mm
	Angle of inclination ：0°
	Weight：≤7.59t
	Applicable working scope: ：Logs，steel pipes
Main Technical Data	Overall weight ：71.2t
	Dimensions： 1246042007290mm
	Wheel base：6000mm
	Minimum ground clearance：350mm
	Front track：3033mm
